Coin cell batteries have become evermore popular over the years and are found in a number of small electronic devices and products including medical devices such as children’s thermometers all the way through to every day products such as watches, calculators, toys, car key fobs, flameless candles and much more. In addition to this, they feature excellent leakage resistance. Please dispose of used batteries in a responsible manner. Keep out of reach of small children.
Nominal Voltage
3V
Nominal Capacity (mAh)*1
140
Nominal Discharge Current (mA)
0.1
Operating Temperature range (deg. C)*2
-20 to +85
Diameter (mm)
16.0mm
Height (mm)
3.2mm
Weight (g)*3
1.9g
Chemical System
Lithium Manganese Dioxide
This Maxell CR1632 battery is called by these names also:
Energizer ECR1632
Duracell DL1632
Rayovac KECR1632
Varta CR1632
