FITTING KIT UNIVERSAL DOUBLE DIN CAGE 110MM (BLACK TRIM)

FITTING KIT UNIVERSAL DOUBLE DIN CAGE 110MM (BLACK TRIM)

$49.95 NZD
$49.95 NZD
Sale Sold out
Taxes included. Shipping calculated at checkout.
110mm Double DIN cradle fitting frame with black plastic trim ring surround

Used to surround a double DIN head unit so it can be mounted and locked into place within the vehicles dash.

Supplied with:
  • Double DIN fitting frame: 180mm across x 110mm high x 100mm deep
  • 1 x Black plastic trim ring surround for finishing the installation neatly and professionally
  • Left and right plates that screw to the head unit and then lock into the double DIN fitting frame
  • 2 x Brackets used for clamping the plates. These brackets allow for the head unit to be moved backwards and forwards in the cradle to move it into a position where it is flush with the dash of the vehicle.
  • Keys for easy removal of the head unit from the double DIN fitting frame
  • 4 x ISO screws for fastening the left and right plates to the sides of the head unit
  • 2 x Foam pads

Cradle Size:
  • Internal Dimensions: 180mm W x 100mm H
  • External Dimensions: 182mm W x 103mm H
  • Mounting Cage Dimensions: 186mm W x 117mm H

Trim Ring Size:
  • Internal Dimensions: 174mm x 97mm H
  • External Dimensions: 188mm W x 118mm H
